10L Aluminum Oxygen Cylinder

High Pressure Aluminum Oxygen Cylinders 10L
Quantity:
  • LWH159-10.0-X
  • CBMTECH
  • General

10L Aluminum Oxygen Cylinder

Our Aluminum alloy gas cylinders can be refilled with rare, high pure, calibration and special gases. They are made of superior quality aluminum alloy and manufactured through the procedures of punching, drawing, heat treatment, CNC flow forming spinning, anodic oxidation treatment to the inner surface, etc. It is used to be filled and refilled with various kinds of gases, such as rare gases, high purity gases, standard gases, special gases, with a wide range of applications in the chemical industry, electronic industry, medical treatment, gas and coal mining fields, which is the ideal substitute for the steel cylinder. We also have the ability to design and produce the seamless aluminum alloy cylinders with special specifications and technical requirements.

Spec. of 10L Aluminum Oxygen Cylinder

-Material.:Al6061;

-OD:159mm;

-W.P/T.P.:15/25Mpa;

-Gas:1.5 M3.

-(Normal)Wall Thickness:8.0mm;

-(Normal)Height: ~735mm;

-(Normal)N.W.:~8.8kg(w/o valve & handle);

-Green silvery;

-Connecting Thread: 3/4-16UNF /PZ 27.8

-W/ normal oxygen valve CGA540 & plastic handle each;

NoSpecificationOuter DiameterWater VolumeLengthWeight Working pressure
1LW-60-0.5-20-H60mm0.5L285mm0.59kg200bar
2LW-75-0.7-15-H75mm0.7L295mm0.85kg150bar
3LW-82-0.7-15-H82mm0.7L235mm0.9kg150bar
4LW-89-1.0-15-H89mm1.0L269mm1.2kg150bar
5LW-89-1.4-15-H89mm1.4L345mm1.4kg150bar
6LW-108-1.0-15-H108mm1.0L210mm1.3kg150bar
7LW-108-1.4-15-H108mm1.4L264mm1.6kg150bar
8LW-108-2.0-15-H108mm2.0L346mm2.1kg150bar
9LW-108-2.5-15-H108mm2.5L413mm2.5kg150bar
10LW-120-2.0-15-H120mm2.0L320mm2.7kg150bar
11LW-120-2.5-15-H120mm2.5L369mm3.0kg150bar
12LW-120-2.8-15-H120mm2.8L398mm3.2kg150bar
13LW-120-3.2-15-H120mm3.2L437mm3.5kg150bar
14LW-140-4.0-15-H140mm4.0L420mm4.2kg150bar
15LW-140-5.0-15-H140mm5.0L500mm4.9kg150bar
16LW140-6.0-15-H140mm6.0L580mm5.6kg150bar
17LW140-8.0-15-H140mm8.0L741mm7.2kg150bar
18LW140-5.0-20-H140mm5.0L525mm6.3kg200bar
19LW140-6.0-20-H140mm6.0L652mm7.98kg200bar
20LW-159-10.0-15-H159mm10.0L730mm8.8kg150bar
21LW-184-9.0-20-H184mm9.0L575mm12.0kg200bar
22LW-184-10-20-H184mm10.0L620mm12.9kg200bar
23LW-184-11-20-H184mm11.0L665mm14.2kg200bar
24LW-184-12-20-H184mm12.0L710mm15.4kg200bar
25LW-203-12-15-H203mm12.0L567mm11.8kg150bar
26LW-203-20-15-H203mm20.0L873mm17kg150bar
27LW-203-21.3-15-H203mm21.3L962mm19.9kg150bar
28LW-204-12-20-H204mm12.0L610mm16.5kg200bar
29LW-204-15-20-H204mm15.0L735mm18.7kg200bar
30LW-204-20-20-H204mm20.0L940mm23.4kg200bar
31LW-232-29.5-15-H232mm29.5L994mm30.2kg150bar
32LW-232-30.0-15-H232mm30.0L1010mm30.5kg150bar
33LW-232-33.4-15-H232mm33.4L1126mm31.3kg150bar
34LW-232-40.0-15-H232mm40.0L1340mm36.5kg150bar
35LW-232-20.0-20-H232mm20.0L750mm26.9kg200bar
36LW-232-26.0-20-H232mm26.0L921mm30.7kg200bar
37LW-232-30.0-20-H232mm30.0L1076mm36.4kg200bar
38LW-232-31.5-20-H232mm31.5L1096mm38kg200bar
39LW-232-40.0-20-H232mm40.0L1365mm44.1kg200bar
40LW-250-40.0-15-H250mm40.0L1150mm36.7kg150bar
41LW-250-46.4-15-H250mm46.4L1305mm38.7kg150bar
42LW-250-47.5-15-H250mm47.5L1340mm42.0kg150bar
43LW-250-50.0-15-H250mm50.0L1590mm39kg200bar
44LW-250-40.0-20-H250mm40.0L1227mm46.3kg200bar
45LW-250-50.0-20-H250mm50.0L1500mm56kg200bar

*About Us:
We can manufacture and supply Seamless Steel Oxygen Cylinders, Portable Oxygen Cylinder Sets, Gas Oxygen Tanks, Oxygen Flowmeters, Medical Oxygen Flow Regulators, Oxygen Cylinder Regulators With Humidifiers, Medical Oxygen Inhalers, Click-style Oxygen Regulators, Wall-type Oxygen Regulators, Reuseable O2 Humidifiers, Disposable Oxygen Humidifiers, Medical Oxygen Cylinders, Aluminum Oxygen Cylinders, Medical Oxygen Kits, Oxygen Intake Devices, Gas O2 Valves, Medical Pin Index Valves, Medical Gas O2 Supply System Products, Gas O2 Cylinder Trolleys, Oxygen Carts, Gas O2 Outlets, Ceiling Medical Pendants, Medical Gas Oxygen Respiratory Products and etc.

*What We Can Manufacture & Supply:
-Different standards of medical gas outlets & adapters, say British standard(BS), French standard(AFNOR), German standard(DIN), American std types(Diss, Ohmeda, Chemetron),and etc.
-Medical oxygen flowmeters and humidifiers, vacuum regulators, surgical pendants, bed head units, zone valves with boxs, gas alarms;
-Medical Gas Cylinders,gas manifolds & related gas valves;
-Related medical/industrial gas system products.

*Advantages We Have:
-1).Original Manuacturer: Being a professional manufacturer, we have professional equipments for our manufactureing products, including Punch Machines, CNC Machines, and etc.;
-2)Large Output capability: We have the capability to produce more than 50, 000PCS of Medical Oxygen Flowmeters each month;
-3)Quality Control: With ISO13485 Quality Management system; All products have been tested before out of factory;
-4)Cost Advantages: We have cost advantage because our professional and scale economy;
-5)Series: We have different series and models, for different standards in different countries;
-6)Small order can be acceptable: M. O. Q. =50PCS;
-7)Exporting experience: We have over 5 years' experience for exporting.

NOTES:
-a). Various types of O2 flowmeter regulators,steel/aluminum O2 gas cylinders,O2 gas cylinder valves,cylinder caps,steel valve guards can be optional;
-b).We have many advantages of satisfying our potential customers' MIXED needs of different sizes of HP steel gas(O2/Helium/Argon/CO2/N2) cylinders raning from 0.2L~68L @15Mpa/20Mpa & ISO3807-1/2 Dissolved  Acetylene Cylinders(2L~60L),as well as HP aluminum gas cylinders & allied gas valves,regulators.

Anyway,should you have any intersts or some more info needed on our gas cylinders & allied gas items(gas cylinder valves,gas regulators,medical hospital central oxygen system products),you are really welcome to enquire us anytime!
