47L Oxygen Cylinders

ISO9809-3 Seamless Steel Oxygen Tanks,47L Seamless Steel Oxygen Bottles/Cylinders for oxygen storage,delivery & supply system.
Availability:
Quantity:
  • WMA232-47-150/O2

  • CBMTEC

  • 73110090

47L Oxygen Cylinders

10

ISO9809-3 Seamless Steel Oxygen Tanks,47L Seamless Steel Oxygen Bottles/Cylinders for oxygen storage,delivery & supply system.

*Referenced main specs of 47L Seamless Steel oxygen gas bottles/cylinders/tanks:
-1).Water capacity:47 Litres; Material.:37Mn; Outer Diameter =232 mm; Working pressure./Testing Pressure.:15/25Mpa; Wall thickness: 5.2 +mm; Gross.Weight.:~49.5kg; Height: ~1,385mm (cylinder body).
Applied standard:ISO 9809-3;
-2).Color: BLACK with shoulder white(as required);
-3).Connecting thread: PZ27.8; With required company's abbreviative name and serial number(to-be-confirmed);
-4).W/ optional O2 Valves QF-2G1(Outlet Thread: Female 5/8''G);
-5).Packing: EA with nylon bag (based on bilateral agreement,400pcs/20ft)
-6).Test reports of cylinders can be provided as per bilateral agreement.
-7).HS code of steel oxygen cylinders:731100.9000


Being a professional manufacturer of gas cylinders, we can produce high-quality seamless steel gas oxygen cylinders from 0.2L to 68L with different stadard specifications as per your kind request(s).
Type Outside Diameter OD. (mm) Water Capacity (L) Height
(W/O valve) (mm)
Weight
(without valve cap)W(kg)
Material Standard
WMA108-1.4-15 108 1.4 238 2.96 37Mn GB5099-3
WMA108-2-15 108 2.0 320 3.75
WMT108-2-15 108 2.0 317 3.72
WMA121-3.2-15 121 3.2 390 5.02
WMT121-3.2-15 121 3.2 385.8 4.98
WMA121-4-15 121 4.0 485 6.16
WMT121-4-15 121 4.0 470 5.95
WMA140-4-15 140 4.0 372 5.77
WMA140-5-15 140 5.0 458 7.52
WMA140-6.3-15 140 6.3 524 8.72
WMA140-7-15 140 7.0 593 9.84
WMA140-8-15 140 8.0 671 10.72
WMA140-10-15 140 10 845 13.4
WMA152-7-15 152 7.0 528 9.57
WMA152-8-15 152 8.0 600 10.66
WMA152-10-15 152 10.0 726 12.6
WMA159-10-15 159 10.0 685 14.15
WMA159-12-15 159 12.0 800 16.34
WMA159-15-15 159 15.0 975 19.66
WMA219-20-15 219 20.0 730 29.00
WMA219-40-15 219 40.0 1310 48.00
WMA232-40-15 232 40.0 1220 50.00
WZA232-47-15 232 47.0 1360 51.00
WMA219-50-15 219 50.0 1600 57.00
WMA232-50-15 232 50.0 1380 65.00
IWGA219-40-15 219 40.0 1380 52.00 34CrMo4 ISO9809-3
IWGA232-40-20 232 40.0 1170 52.00
IWGA232-47-20 232 47.0 1360 55.00
IWGA232-50-20 232 50.0 1440 56.00
Notes: -1)...WMA-Concave Bottom WMT-Convex Bottom;
             -2). Hydraulic test pressure: 25Mpa or 30Mpa;
             -3). Working test pressure: 15Mpa or 20Mpa;

             -4). Various types of gas cylinders accessaries, say gas cylinder valves, cylinder caps, gas regulators can be also offered up further kind requirement(s).


About Us:


We are a professional manufacturer and supplier of Gas Cylinders Regulators, Oxygen Flowmeters, Medical Oxygen Flow Regulators, Medical Oxygen Kits, Oxygen Intake Devices, Gas O2 Valves, Medical Pin Index Valves, Medical Gas O2 Supply System Products, Gas O2 Cylinder Carts/Trolleys, Gas O2 Outlets, Ceiling Medical Pendants, Medical Gas Oxygen Respiratory Products and etc.


Advantages :
-1).Original Manuacturer: Being a professional manufacturer, we have professional equipments for our manufactureing products, including Punch Machines, CNC Machines, and etc.;
-2)Large Output capability: We have the capability to produce more than 50, 000PCS of Medical Oxygen flowmeters each month;
-3)Quality Control: With ISO13485 Quality Management system; All products have been tested before out of factory;
-4)Cost Advantages: We have cost advantage because our professional and scale economy;
-5)Series: We have different series and models, for different standards in different countries;
-6)Small order can be acceptable: M. O. Q. =50PCS;
-7)Exporting experience: We have over 5 years' experience for exporting.


What we can promise for you:
*High quality and security gas cylinders;
*Competitive unit price in the market;
*Fast delivery (3~4 weeks);
*Best after-sale service.


NOTES:
-a). Various types of seamless steel/aluminum gas cylinders,cylinder valves & flowmeter regulators can be optional;

-b). We have many advantages of satisfying our potential customers' MIXED needs of different sizes of HP steel gas(O2/Helium/Argon/CO2/N2) cylinders raning from 0.2L~68L @15Mpa/20Mpa & ISO3807-1/2 Dissolved  Acetylene Cylinders(2L~60L),as well as cylinder regulators & cylinder carts.


Anyway,should you have any intersts or some more info needed on our cylinder carts, medical/industrial gas cylinders & allied gas items(gas cylinder valves,gas cylinder regulators,medical hospital central oxygen system products),you are really welcome to enquire us anytime!
